Product Overview

Laser cleaning equipment is a new generation of high-tech product for surface cleaning. It is easy to install, operate, and automate. With simple operation, just connect the power, turn on the equipment, and you can start cleaning without chemical reagents, media, dust, or water. It has advantages such as automatic focusing, fitting curved surfaces, high cleanliness of the cleaned surface, and the ability to remove resin, oil, stains, dirt, rust, coatings, platings, and paint from the surface of objects.

Features of the equipment

◆ The product is designed with an anti-reflection system to prevent damage to optical components

◆ Anti-stain function: When cleaning precision objects, the surface of the object is free of stains

◆Zebra pattern removal function, an original software feature for removing patterns

Application Industry

The industry is primarily applied to precision cleaning, suitable for cleaning small items

◆ Abrasive tool industry: rubber residue, oxides, residual rubber, etc

◆ Automotive industry: oil stains, rust, oxides, paint, etc

◆ Electronics industry: oxides, paints, residual adhesives

◆ Plastics industry: peeling of layers on the surface of plastic products
Product parameters

parameter50W100W200W500W
Typepulsed fiberpulsed fiberpulsed fiberpulsed fiber
wavelength1064nm1064nm1064nm1064nm
average power50W100W200W500W
Peak power5kW10kW20kW50kW
pulse frequency20–100kHz20–100kHz20–100kHz20–100kHz
pulse width100ns100ns100ns100ns
Scanning width0–150mm0–150mm0–150mm0–150mm
cooling methodair coolingair coolingair coolingwater cooling
Power supply220V/50Hz220V/50Hz220V/50Hz220V/50Hz
Size(mm)600×450×300600×450×300700×500×350800×600×400
Weight45kg50kg75kg120kg
